CRT MICRON UV

PM 000730

New product

  • UHF-VHF DUAL BAND MOBILE TRANSCEIVER
  • RX/TX : 144-146 MHz -- 430-440 MHz
  • 20W UHF - 25W VHF

More details

119,00 € tax incl.

Data sheet

Norm AMATEUR RADIO
Mode FM ( Wide/Narrow )
Frequency range RX/TX : 144-146 MHz / 430-440 MHz (Exp 136-174 MHz / 400-490 MHz)
Power LOW : 5W / MIDDLE : 15W / HIGHT : 25W VHF -- 20W UHF(large cooling box)
Input voltage 13,8V DC
Memories 200 channels
Channel spacing 12.5 / 20 / 25 KHz
Step of increment 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 KHz
Working UU / UV / VU / VV
RELAY MOD Yes : allows to enter a relay with two different frequency
TONE BURST Yes : 1000Hz / 1450Hz / 1750Hz / 2100Hz
CTCSS / DCS (encoder/decoder) 52 CTCSS / 1024 DCS : sub-audio code to activate repeater like selective tone
DTMF (encoder) Yes : tones selected to activate repeater, internet gateway and other items
DOUBLE WATCH function Yes
TOT function Yes : time out timer
CTCSS / DCS SCAN function Yes
SCAN function Yes : automatic search of busy channels
REVERSE function Yes : the current channel RX frequency will be switched to TX frequency
TALK AROUND function Yes : switch RX/TX frequencies and CTCSS/DCS code to avoid using repetear
Various functions Possibility to lock the start by code (default code 123456)
Bonus Backlit keys + Jack plug for external loud speaker + 6 functions keys PF1 to PF6 with 3 functions each + menu order can be personalized
Mike With speaker incorpored and programmable keys
Display Large color multifunction TFT display adjustable to 180 °
Level display RX signal + TX power + channel number or frequency + various functions ...
Options Programming cable + software
Programmable by software Yes
Size 122 (l) x 165 (L) x 35 (H) mm
Weight 480 gr
Guaranty 2 years
