SIGNAL KEEPER SIRIO

VS 000214

New product

BASE ANTENNA CB

26...28 MHz No tuning required /

1/4 λ /

0 dBd, 2.15 dBi /

2370 mm

More details

This product is no longer in stock

46,00 € tax incl.

More info

Type: 1/4 λ base loaded ground plane
Radiation: Omnidirectional
Polarization: Linear vertical
Frequency range: 26-28 MHz No tuning required
Systems: 10m-HAM
Gain: 0 dBd, 2.15 dBi
Bandwidth: ≥ 850KHz @ SWR ≤ 2
Max Power: 100 Watts (CW) continuous
300 Watts (CW) short time
Connector: UHF-female (SO-239)
Mechanical Data:
Materials: Aluminium, Chromed brass, Stainless steel, Nylon, Zamak
Height (approx): 2370 mm / 7.78 ft
Weight (approx): 640 gr / 1.41 lb
Mounting type: On-Mast
