SUPER 9 BLUE LINE SIRIO

Reference: VS 000172

Condition: New product

MOBILE CB ANTENNA

27…28.5 MHz Tunable /

1550 mm

More details

Electrical Data:

Type:	base loaded
Radiation:	Omnidirectional
Polarization:	Linear vertical
Frequency range:	27 … 28.5 MHz Tunable
Systems:	CB 27MHz, 10m-HAM
Bandwidth:	≥ 1.9MHz @ SWR ≤ 2
Max Power:	35 Watts (CW) continuous; 250 Watts (CW) short time
Cable lenght / type:	4 m (13.12 ft) / RG58 + FME
Connector:	Adaptator FME/PL

Mechanical Data:

Materials:	Copper, Brass, Stainless Steel 17/7 PH, Nylon
Height (approx):	1550 mm / 5.09 ft
Weight (approx):	420 gr / 0.93 lb
Mounting type:	Thru-Hole
